• MasterMap

    The most consistent, extensive, and reliable digital representation of the geography of Great Britain available provided by the Ordnance Survey in CAD, PDF, PNG and GML formats to help create your location plans.

  • Freehold Boundaries

    Regularly updated from the Land Registry this extra layer demonstrates the locations of freehold registered estate in England and Wales suitable for CAD software to contribute to your location plans.

  • Building Heights

    Maximum, minimum and average heights are provided for each building. It is available as an extra layer for your location plans in CAD and GIS format.

  • 1m Contours

    Contour lines based on detailed LiDAR surveys to aid in understanding the shape of the ground for your location plans. Available as CAD layers.

  • National Tree Map™

    The most detailed dataset of its kind, it offers coverage across England and Wales of millions of trees, 3m and above, suitable for your location plans.

  • Aerial Photographs

    Aerial photos with varying resolutions and dates. Downloadable in PNG format to accompany your location plans.

Professional Location Plans from £13.72

  • Mastermap, contours, freehold boundaries, building heights in DWG, DXF, PDF & more
  • Save money compared to your current provider, plus get free MasterMap previews.
  • Superb map design = faster projects
OS Partner logo
RIBA CPD logo
Member of the public?
Use Buyaplan.co.uk →

Helpful tools for your Location plans

auto-outline
options
papersize
rectangle
save-area
snap-to-point

Auto Outline

Easily mark the borders of a property boundary or just the property on your location plans.

Options

Choose from a broad range of professional mapping in CAD formats such as DWG and DXF to complete your location plans.

Papersize

Fit your location plan perfectly to your selected scale, paper size, and orientation using the Papersize tool.

Rectangle

Using the Rectangle tool, define the size of your map area. Other tools to select your location plan include Polygon and Set Area.

Save Area

Save a specific area with a reference title of your choosing for further use in location plans.

Snap to Point

To partially define a property limit or feature, you can use the Snap to Point tool in your location plans.

Many Customers, Many Uses

The Telecoms Surveyor

Before the site visit, David must spot mast access points and locate nearby estates that need to be notified of the work and prepare EMF (electromagnetic field) reports to assist clients in establishing safe working practises around telecom apparatus.

The Architect

Leigh generally orders MasterMap in DWG format, which he later overlays on sketches on a table to find new access points and how sites relate to projects. To do site appraisals and location plans, he also combines the maps with Google area views and street views.'

The Town Planner

Stuart’s office uses mapping for a variety of tasks, including planning applications, checking planning constraints such as listed buildings, planning precedents and they create certificates of lawfulness/lawful use, which can include evidence like aerial imagery.

The Transport Planning Consultant

Myles generally orders coloured and black-and-white MasterMap in CAD formats. He uses maps that cover over 300 metres from the site he is working on, which he then transfers to his CAD software to create the necessary location plans.'

The Arboricultural Consultant

Robert purchases location plans in DWG format before going on-site and downloads it to his survey tablet, which has embedded survey software and GPS. He then combines his integrated tree software with AutoCAD to plot the trees and their positions to create different layers for the reports that he produces for his clients.

Supported Software

3D studio max logo Adobe Acrobat logo Graphisoft Archicad logo Autodesk Autocad LT logo Autodesk Autocad logo Catia logo Autodesk Civil 3D logo Solidworks logo Edge logo Planxpress logo Pro Landscape logo QGIS logo Autodesk Revit logo Rhinoceros logo Sketchup logo Tinkercad logo Vectorworks logo
